[this article was originally published on blog.safecast.org. We thank the author and the editors.]
This grating inside Daiichi Unit 2 was likely melted by falling fuel debris (TEPCO photo)
— Yes, TEPCO has measured very high radiation inside Daichi Unit 2.
— No, it does’t mean radiation levels there are rising.
In response to visual investigation results and high radiation measurements recently taken by TEPCO inside Fukushima Daiichi Unit 2, many news outlets have published stories with headlines like “Fukushima nuclear reactor radiation at highest level since 2011 meltdown.” (The Guardian, Feb. 3, 2017).
This has led to a number of alarming stories claiming that radiation at Daiichi has “spiked” to unprecedented levels. That’s not what the findings indicate, however. In addition, Safecast’s own measurements, including our Pointcast realtime detector system have shown radiation levels near Daiichi to be steadily declining. As described in the Safecast Report, Vol.2, Section 2.1.4, TEPCO and its research partners have been developing robots and remote visualization devices to search for melted fuel debris deep inside the Daiichi reactor units, and to help plan for its eventual removal. On January 30th, 2017, a long telescoping device with a camera and radiation measurement device attached was inserted through an existing opening in the reactor containment of Unit 2 for the first time, and successfully extended approximately 8 meters into in an area known as the “pedestal,” to measure and take images from immediately below the damaged reactor pressure vessel (RPV). In addition to finding the area covered with molten material likely to be fuel debris, radiation levels of 530 Sieverts per hour were detected, which would be fatal to a person exposed for only a few seconds.
The recent investigation used existing openings in the Unit 2 reactor to obtain images an measurements inside the pedestal area.(TEPCO image)
The telescoping arm (in yellow) was designed to reach inside the pedestal area to obtain visual imagery and radiation measurements.(TEPCO image)
It must be stressed that radiation in this area has not been measured before, and it was expected to be extremely high. While 530 Sv/hr is the highest measured so far at Fukushima Daiichi, it does not mean that levels there are rising, but that a previously unmeasurable high-radiation area has finally been measured. Similar remote investigations are being planned for Daiichi Units 1 and 3. We should not be surprised if even higher radiation levels are found there, but only actual measurements will tell. Unit 4 was defuelled at the time of the accident, and though the reactor building exploded and the spent fuel pool was dangerously exposed, it did not suffer a meltdown, so similar investigations are not being conducted.
The “Scorpion” crawler robot is designed to be inserted through a pipe and to fold for operation. It’s deployment is likely to be further delayed.(IRID photo)
Under a consortium called IRID, TEPCO and its research partners have been developing robots and other devices to assist in investigations inside the damaged reactors, where radiation levels are too high to allow humans to safely enter. The recent investigations at Unit 2 were intended to help plan the travel path of a folding crawler robot called the “Scorpion.” This device is designed to crawl around on the metal grating deck inside the pedestal and gather further imagery and measurements. The recent investigations, however, have revealed a 1×1 meter section of the deck to be melted through, and much of the rest may be impassable for the robot. In addition, the high radiation levels will likely limit the amount of time the robot will be able to operate before malfunctioning to about 2 hours, instead of the planned 10 hours. Much more melted fuel debris is assumed to have settled beneath the pedestal grating on the concrete basemat of the reactor. It was hoped that the Scorpion would be able to provide imagery of this. Not surprisingly, TEPCO is once again revising its plans based on the recent findings. These investigations are technically quite impressive, but they have already been delayed for over a year due to the need to more adequately decontaminate the area where human workers must operate and to solve other technical problems. This recent imagery is extremely informative and helpful, and had been eagerly awaited by many concerned people, including Safecast. If nothing else, we have learned to be patient as TEPCO proceeds slowly and cautiously with this work. The process of removing melted fuel debris from the damaged reactors at Fukushima Daiichi is expected to take decades, and these recent findings remind us once again that TEPCO has little grounds for optimism about the challenges of this massive and technically unprecedented project.
Stitched vertical panorama showing conditions underneath the Unit 2 RPV. (TEPCO photo)
